Quantum QX Series User Manual

Chapter 6: LEDDescriptions
LEDs for 56-Drive RAID Chassis (4U56)
QX and QXS Setup Guide 179
LEDmode
description
Color State Definition
2—Fault Amber On
Blink
Off
The drive has failed; experienced a fault; is a leftover; or the drive group that
it is associated with is down or critical.
Physically identifies the drive; or locates a leftover (also see Blue).
If not illuminated and Power/Activity is not illuminated, the drive is not
powered on.
Blue Blink Leftover drive from drive group is located (alternates blinking amber).
Table 56 below provides additional information on the QXS-456 LFF drive LEDs.
DrivemoduleLEDbehavior LFFdrives
Description State Color Action
Drive OK, FTOL Off None None
On (operating normally) Green On
OK to remove Green Blink
Blue On
Identifying self - offline/online Green
1
On
Amber Blink
Drive I/O Initializing Green Blink
Active and processing I/O Green Blink
Performing a media scan Green Blink
Drive leftover Drive is a leftover Amber On
Identifying a leftover Amber Blink
Blue
1
On
Table56:LEDs: Drives in LFF chassis
