Quantum QX Series User Manual

Chapter 1: Components
QXS-4 Series and StorNext Storage
QX and QXS Setup Guide 12
2U24-Drive Chassis
Figure15:2U Drive Chassis (Bezel Installed)
5
6
7
8
1
2
3
4
5
1. ChassisIDLED
2. ChassisStatusLED:UnitLocator
3. ChassisStatusLED:Fault/ServiceRequired
4. ChassisStatusLED:FRUOK
5. ChassisStatusLED:TemperatureFault
Figure16:2U24 Drive Chassis (bezel removed)
Left Ear Right Ear
32
1
1. ChassisIDLED
2. DriveStatusLED:Power/Activity
3. DriveStatusLED:Fault
NotShown-2.5"DriveBlank
2U48-Drive chassis
The 2U48 drive chassis is used in QXS-448.
