Quantum QX Series User Manual

Chapter 1: Components
QXS-4 Series and StorNext Storage
QX and QXS Setup Guide 13
Figure17:2U Drive Chassis (Bezel Installed)
5
6
7
8
1
2
3
4
5
1. ChassisIDLED
2. ChassisStatusLED:UnitLocator
3. ChassisStatusLED:Fault/ServiceRequired
4. ChassisStatusLED:FRUOK
5. ChassisStatusLED:TemperatureFault
Figure18:2U48 Drive chassis (Bezel Removed)
Note:Integers atop drawers indicate drawer numbering sequence.
1. ChassisearLEDs
2. Thumbscrew(forsecuringoraccessingdrawers)
3. DisabledButton(usedbyengineeringonly)
4. DrawerHandle(showninstowedposition)
5. DrawerStatusLED:FRUOK
6. DrawerStatusLED:Fault/ServiceRequired
7. DrawerStatusLED:OKtoRemove
8. DrawerStatusLED:UnitLocator
