Chapter 2: Installing the Chassis
Install Drives Into the QXS 12-Drive and 24-Drive Chassis
QX and QXS Setup Guide 53
CORE Issue 3 — together with adjacent page locations. NEBS topics are integrated within the overall
content of this setup guide. The requirement designators in the Index have been codified for use within index
marker tags according to the following example:
NEBS generic requirement number “R1-3 [155]” appears as “R1-3.155” within the Index.
Each codified string (e.g., R1-3.155) is followed by a hyphen and brief description of the requirement. Within
the Index, click on the blue page number link to navigate to the corresponding NEBS topic.
Install Drives Into the QXS 12-Drive and 24-
Drive Chassis
This section covers the following systems:
l QXS-312 and QXS-412 (2U12 chassis)
l QXS-324 and QXS-424 (2U24 chassis)
l QXS-1200 (2U12 chassis)
l QXS-2400 (2U24 chassis)
l QX-1200 (2U12 chassis)
l QX-2400 (2U24 chassis)
Prerequisites
Review the following information before populating the 12-drive or 24-drive chassis.
l Full Disk Encryption (FDE) firmware feature. See FDEConsiderations in the QX and QXS Setup
Guide.
l Preventing electrostatic discharge. See Take ESD Precautions.
Installation Steps
l You will use the same processes for removing and installing the bezel for the 12- and 24-drive
chassis:
o
Step 3: Install the Bezel (2U12 or 2U24 Chassis) on page 55
l To install the drives, use the appropriate installation task for your chassis type.
o
Step 2a: Install the LFF Drives into the 2U12 Chassis on the next page
o
Step 2b: Install the Drives into the 2U24 Chassis on the next page
For both chassis types, the drives are located behind the bezel. The difference between the two is that
the drives are installed horizontally in the 12-drive chassis but vertically in the 24-drive chassis.
