Quantum QX Series User Manual

Chapter 1: Components
2U12, 2U24, and 2U48 RAID Chassis: Rear Panel Layout
QX and QXS Setup Guide 17
Figure22:Controller I/O Module with FC or iSCSI Host CNC Ports
LINK SERVICE–1
CACHE
DIRTY
CLEAN
LINK
ACTSERVICE–2 CLI
CLI
PORT 0 PORT 1
PORT 2 PORT 3
1
2 3 4 5
6
7 8
1. CNCFCoriSCSIwithSFP+Ports(usedforhost
connectionorreplication;supportsSFP+FC
transceivers)
2. CLIPort(USB-TypeB)
3. ServicePort2(ServicePersonnelUseOnly)
4. ReservedforFutureUse
5. NetworkPort
6. ServicePort1(ServicePersonnelUseOnly)
7. DisabledButton(usedbyengineeringonly)
(Stickershowncoveringtheopening)
8. Mini-SASExpansionPort
1. iSCSIwithSFP+Ports(usedforhostconnectionor
replication;supportsSFP+FCtransceivers)
2. CLIPort(USB-TypeB)
3. ServicePort2(ServicePersonnelUseOnly)
4. ReservedforFutureUse
5. NetworkPort
6. ServicePort1(ServicePersonnelUseOnly)
7. DisabledButton(usedbyengineeringonly)
(Stickershowncoveringtheopening)
8. Mini-SASExpansionPort
Host CNC Ports Configured with SFPs (1-Gb RJ-45)
Figure 23 on the next page shows a controller IOM with CNC ports configured with SFPs supporting 1-Gb
RJ-45.
