2.7. Analog Input/Digital Input
There is one input can be configured as an analog input or a digital input on GV58CEU.
For the analog input/ digital input, the range of input voltage is from 0V to 30V.
The following diagram shows the recommended connection.
Figure 7: Connection for Analog Input/Digital Input
2.8. 1-WIRE Interface
There are two lines dedicated to the 1-WIRE, VDD and Data for one wire.
Figure 8: 1-WIRE Interface
IN2/AIN1 (Blue)
GND (Black)
Data 1Wire (Pink)
VDD 1Wire (Brown)
