Quectel EC25-AUX

LTE Standard Module Series
EC25 Hardware Design
EC25_Hardware_Design 100 / 130
Table 45: EC25-MX Current Consumption
LTE-TDD B41 @23.17dBm 483.2 mA
GSM
voice call
EGSM900 PCL=5 @32.81dBm 262.2 mA
DCS1800 PCL=0 @29.62dBm 151.2 mA
WCDMA voice
call
WCDMA B1 @23.09dBm 594.2 mA
WCDMA B8 @23.18dBm 504.3 mA
Parameter Description Conditions Typ. Unit
I
VBAT
OFF state Power down 19 uA
Sleep state
AT+CFUN=0 (USB disconnected)
1.0 mA
WCDMA PF=64 (USB disconnected) 2.3 mA
WCDMA PF=128 (USB disconnected) 1.7 mA
LTE-FDD PF=64 (USB disconnected) 2.5 mA
LTE-FDD PF=128 (USB disconnected) 2.2 mA
Idle state
WCDMA PF=64 (USB disconnected) 12.9 mA
WCDMA PF=64 (USB connected) 32.0 mA
LTE-FDD PF=64 (USB disconnected) 13.7 mA
LTE-FDD PF=64 (USB connected) 32.6 mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B2 HSDPA @22.27dBm 581.9 mA
WCDMA B2 HSUPA @22.15dBm 603.0 mA
WCDMA B4 HSDPA @22.5dBm 578.0 mA
WCDMA B4 HSUPA @22.5dBm 571.0 mA
WCDMA B5 HSDPA @22.4dBm 499.0 mA
WCDMA B5 HSUPA @22.17dBm 515.0 mA
LTE data LTE-FDD B2 @23.2dBm 685.0 mA
