Quectel EC25-AUX

LTE Standard Module Series
EC25 Hardware Design
EC25_Hardware_Design 101 / 130
Table 46: EC25-AUX Current Consumption
transfer
(GNSS OFF)
LTE-FDD B4 @23.4dBm 744.0 mA
LTE-FDD B5 @23.2dBm 578.0 mA
LTE-FDD B7 @24.3dBm 868.0 mA
LTE-FDD B28 @23.45dBm 631.0 mA
LTE-FDD B66 @22.68dBm 781.0 mA
WCDMA voice
call
WCDMA B2 @23.47dBm 643.0 mA
WCDMA B4 @23.5dBm 633.0 mA
WCDMA B5 @23.5dBm 551.0 mA
Parameter Description Conditions Typ. Unit
I
VBAT
OFF state Power down 9 uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.9 mA
GSM DRX=2 (USB disconnected) 2.4 mA
LTE-FDD PF=128 (USB disconnected) 2.5 mA
LTE-TDD PF=64 (USB disconnected) 3.4 mA
Idle state
GSM DRX=5 (USB disconnected) 16.9 mA
GSM DRX=5 (USB connected) 34.5 mA
WCDMA PF=64 (USB disconnected) 17.9 mA
WCDMA PF=64 (USB connected) 35.2 mA
LTE-FDD PF=64 (USB disconnected) 18.3 mA
LTE-FDD PF=64 (USB connected) 35.1 mA
LTE-TDD PF=64 (USB disconnected) 18.4 mA
LTE-TDD PF=64 (USB connected) 35.1 mA
GPRS data GSM850 4DL/1UL @32.48dBm 240.1 mA
