5G Module Series
RM502Q-GL Hardware Design
RM502Q-GL_Hardware_Design 24 / 83
3 Operating Characteristics
3.1. Operating Modes
The table below briefly summarizes the various operating modes to be mentioned in the following
chapters.
Table 6: Overview of Operation Modes
3.1.1. Sleep Mode
DRX of the module is able to reduce the current consumption to a minimum value during the sleep mode,
and DRX cycle index values are broadcasted by the wireless network. The figure below shows the
relationship between the DRX run time and the current consumption in sleep mode. The longer the DRX
cycle is, the lower the current consumption will be.
Mode
Details
Normal
Operation
Idle
Software is active. The module has registered on the network, and it is
ready to send and receive data.
Talk/Data
Network is connected. In this mode, the power consumption is
determined by network setting and data transfer rate.
Minimum
Functionality
Mode
AT+CFUN=0 command sets the module to a minimum functionality mode without
removing the power supply. In this mode, both RF function and (U)SIM card are
invalid.
Airplane Mode
AT+CFUN=4 command or driving W_DISABLE1# pin LOW will set the module to
airplane mode. In this mode, the RF function is invalid.
Sleep Mode
The module keeps receiving paging messages, SMS, voice calls and TCP/UDP data
from the network with its current consumption reducing to the minimal level.
Power Down
Mode
In this mode, the power management unit shuts down the power supply. Software is
inactive, all application interfaces are inaccessible, and the operating voltage
(connected to VCC) remains applied.
