LTE-FDD B18 (10 MHz)
-100
-101
-103
-96.3 dBm
LTE-FDD B19 (10 MHz)
-100
-101
-103
-96.3 dBm
LTE-FDD B20 (10 MHz)
-100
-101
-103
-93.3 dBm
LTE-FDD B25 (10 MHz)
-98
-99
-101
-92.8 dBm
LTE-FDD B26 (10 MHz)
-99.5
-101
-103
-93.8 dBm
LTE-FDD B28 (10 MHz)
-100
-101
-103
-94.8 dBm
LTE-FDD B30 (10 MHz)
-97
-98.5
-100.5
-95.3 dBm
LTE-FDD B32 (10 MHz)
-97
-98
-100
-95.3 dBm
LTE-TDD B34 (10 MHz)
-97
-98
-100
-96.3 dBm
LTE-TDD B38 (10 MHz)
-97
-98
-100
-96.3 dBm
LTE-TDD B39 (10 MHz)
-97
-98
-100
-96.3 dBm
LTE-TDD B40 (10 MHz)
-97
-97.5
-100
-96.3 dBm
LTE-TDD B41 (10 MHz)
-97
-98
-100
-94.3 dBm
LTE-TDD B42 (10 MHz)
-97.5
-97.5
-100.5
-95 dBm
LTE-TDD B43 (10 MHz)
-97.5
-97.5
-100.5
-95 dBm
LTE-TDD B48 (10 MHz)
-98.5
-97.5
-101
-95 dBm
LTE-FDD B66 (10 MHz)
-97
-98.5
-100
-95.8 dBm
LTE-FDD B71 (10 MHz)
-100
-101
-103
-93.5 dBm
5G NR
5G NR-FDD n1 (20 MHz)
(SCS: 15 kHz)
-92.5
-92
-95
-94.0 dBm
5G NR-FDD n2 (20 MHz)
(SCS: 15 kHz)
-92
-92
-95
-92.0 dBm
5G NR-FDD n3 (20 MHz)
(SCS: 15 kHz)
-92
-92
-95
-91.0 dBm
5G NR-FDD n5 (10 MHz)
(SCS: 15 kHz)
-96.5
-97
-99.5
-95.0 dBm
5G NR-FDD n7 (20 MHz)
(SCS: 15 kHz)
-92
-91.5
-94
-92.0 dBm
5G NR-FDD n8 (10 MHz)
(SCS: 15 kHz)
-96
-96
-99
-94.0 dBm
