Quectel RM502Q-GL - Page 72

5G Module Series
RM502Q-GL Hardware Design
RM502Q-GL_Hardware_Design 71 / 83
LTE-TDD PF = 64 @ USB Suspend
5.50
mA
Idle state
WCDMA PF = 64 (USB disconnected)
31.43
mA
WCDMA PF = 64 (USB connected)
53.18
mA
LTE-FDD PF = 64 (USB disconnected)
29.41
mA
LTE-FDD PF = 64 (USB connected)
50.86
mA
LTE-TDD PF = 64 (USB disconnected)
29.32
mA
LTE-TDD PF = 64 (USB connected)
50.75
mA
WCDMA
(GNSS OFF)
WCDMA B1 HSDPA CH10700 @ 23 dBm
535
mA
WCDMA B1 HSUPA CH10700 @ 23 dBm
489
mA
WCDMA B2 HSDPA CH9800 @ 23 dBm
540
mA
WCDMA B2 HSUPA CH9800 @ 23 dBm
561
mA
WCDMA B3 HSDPA CH1338 @ 23 dBm
541
mA
WCDMA B3 HSUPA CH1338 @ 23 dBm
515
mA
WCDMA B4 HSDPA CH1638 @ 23 dBm
493
mA
WCDMA B4 HSUPA CH1638 @ 23 dBm
477
mA
WCDMA B5 HSDPA CH4407 @ 23 dBm
401
mA
WCDMA B5 HSUPA CH4407 @ 23 dBm
397
mA
WCDMA B6 HSDPA CH4400 @ 23 dBm
403
mA
WCDMA B6 HSUPA CH4400 @ 23 dBm
398
mA
WCDMA B8 HSDPA CH3012 @ 23 dBm
403
mA
WCDMA B8 HSUPA CH3012 @ 23 dBm
398
mA
WCDMA B19 HSDPA CH738 @ 23 dBm
406
mA
WCDMA B19 HSUPA CH738 @ 23 dBm
420
mA
LTE (GNSS
OFF)
LTE-FDD B1 CH300 @ 23 dBm
725
mA
LTE-FDD B2 CH900 @ 23 dBm
650
mA
