LTE-FDD B71 CH68761 @ 23 dBm
465
mA
5G NR (GNSS
OFF)
1)
5G NR-TDD n41 CH518598 @ 26 dBm
470
mA
5G NR-TDD n77 CH650000 @ 26 dBm
427
mA
5G NR-TDD n78 CH636666 @ 26 dBm
410
mA
5G NR-FDD n1 CH428000 @ 23 dBm
690
mA
5G NR-FDD n2 CH392000 @ 23 dBm
658
mA
5G NR-FDD n3 CH368500 @ 23 dBm
705
mA
5G NR-FDD n5 CH176300 @ 23 dBm
509
mA
5G NR-FDD n7 CH531000 @ 23 dBm
678
mA
5G NR-FDD n8 CH188500 @ 23 dBm
520
mA
5G NR-FDD n12 CH147500 @ 23 dBm
500
mA
5G NR-FDD n20 CH161200 @ 23 dBm
480
mA
5G NR-FDD n25 CH392500 @ 23 dBm
658
mA
5G NR-FDD n28 CH156100 @ 23 dBm
474
mA
5G NR-TDD n38 CH519000 @ 23 dBm
385
mA
5G NR-TDD n40 CH470000 @ 23 dBm
345
mA
5G NR-TDD n48 CH641666 @ 23 dBm
402
mA
5G NR-FDD n66 CH429000 @ 23 dBm
661
mA
5G NR-FDD n71 CH126900 @ 23 dBm
474
mA
WCDMA voice
call
WCDMA B1 CH10700 @ 23 dBm
597
mA
WCDMA B2 CH9800 @ 23 dBm
616
mA
WCDMA B3 CH1338 @ 23 dBm
613
mA
WCDMA B4 CH1638 @ 23 dBm
542
mA
WCDMA B5 CH4408 @ 23 dBm
435
mA
WCDMA B6 CH4175 @ 23 dBm
438
mA
