UMTS/HSPA Module Series
UC20 Hardware Design
UC20_Hardware_Design Confidential / Released 11 / 84
2 Product Concept
2.1. General Description
UC20 is an embedded HSPA+ engine with Rx-diversity. Its UMTS-based modem provides data
connectivity on HSPA+, HSDPA, HSUPA, WCDMA, networks. It can also provide GPS/GLONASS and
voice functionality for customers’ specific application. UC20 offers a maximum data rate of 14.4Mbps on
downlink and 5.76Mbps on uplink in HSPA+/HSPA mode.
Table 1: UC20 Series Frequency Bands
With a tiny profile of 32.0mm × 29.0mm × 2.5mm, UC20 can meet almost all requirements for M2M
application such as automotive, metering, tracking system, security solutions, routers, wireless POS,
mobile computing devices, PDA phone and tablet PC, etc..
UC20 is an SMD type module, which can be embedded in application through its 112-pin pads including
72 LCC signal pads and 40 other pads.
UC20 is integrated with internet service protocols like TCP/UDP and PPP. Extended AT commands have
been developed for customer to use these internet service protocols easily.
2.2. Directives and Standards
The UC20 module is designed to comply with the FCC statements. FCC ID: XMR-201312UC20
The Host system using UC20, should have label indicated FCC ID: XMR-201312UC20.
