UMTS/HSPA Module Series
UC20 Hardware Design
UC20_Hardware_Design Confidential / Released 32 / 84
PWRKEY
S1
Close to S1
TVS
Figure 9: Turn on the Module Using Keystroke
The turn on scenarios is illustrated as the following figure.
