UMTS/HSPA Module Series
UC20 Hardware Design
UC20_Hardware_Design Confidential / Released 65 / 84
6.2. Power Supply Ratings
Table 31: The Module Power Supply Ratings
Voltage must stay within the
min/max values, including voltage
drop, ripple and spikes.
6.3. Operating Temperature
The operating temperature is listed in the following table.
Table 32: Operating Temperature
1. “
1)
” When the module works within the temperature range, the deviations from the RF specification
may occur. For example, the frequency error or the phase error would increase.
2. The maximum surface temperature may be up to 100ºC when module works at 85ºC ambient
temperature.
6.4. Current Consumption
The values of current consumption are shown below.
