Quectel UC20 User Manual

UMTS/HSPA Module Series
UC20 Hardware Design
UC20_Hardware_Design Confidential / Released 67 / 84
GNSS tracking current is tested in the following conditions:
 For Cold Start, 10 minutes after First Fix.
 For Hot Start, 15 seconds after First Fix.
6.5. RF Output Power
The following table shows the RF output power of UC20 module.
Table 34: Conducted RF Output Power
Frequency
Max.
Min.
UMTS 1900
22.5dBm+1/-1dB
<-50dBm
UMTS 850
22.5dBm+1/-1dB
<-50dBm
6.6. RF Receiving Sensitivity
The following table shows the conducted RF receiving sensitivity of UC20 module.
Table 35: Conducted RF Receiving Sensitivity
Frequency
Receive Sensitivity (Typ.)
UMTS 1900
-110dBm
UMTS 850
-110dBm
6.7. Electrostatic Discharge
The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
application that incorporates the module.
The following table shows the module electrostatics discharge characteristics.
