RXD
68
DI
Receive data.
V
IL
min = -0.3V
V
IL
max = 0.6V
V
IH
min = 1.2V
V
IH
max = 2.0V
1.8V power domain.
Debug UART Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
DBG_TXD
12
DO
Transmit data.
V
OL
max = 0.45V
V
OH
min = 1.35V
1.8V power domain.
DBG_RXD
11
DI
Receive data.
V
IL
min = -0.3V
V
IL
max = 0.6V
V
IH
min = 1.2V
V
IH
max = 2.0V
1.8V power domain.
RF Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
ANT_DIV
35
AI
Diversity antenna.
50Ω impedance
ANT_MAIN
49
IO
Main antenna.
50Ω impedance
ANT_GNSS
47
AI
GNNS antenna.
50Ω impedance
PCM Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
PCM_IN
24
DI
PCM data input.
V
IL
min = -0.3V
V
IL
max = 0.6V
V
IH
min = 1.2V
V
IH
max = 2.0V
1.8V power domain.
PCM_OUT
25
DO
PCM data output.
V
OL
max = 0.45V
V
OH
min = 1.35V
1.8V power domain.
PCM_SYNC
26
IO
PCM data frame
sync signal.
V
OL
max = 0.45V
V
OH
min = 1.35V
V
IL
min = -0.3V
V
IL
max = 0.6V
V
IH
min = 1.2V
V
IH
max = 2.0V
1.8V power domain.
In master mode, it is
an output signal. In
slave mode, it is an
input signal.
PCM_CLK
27
IO
PCM data bit clock.
V
OL
max = 0.45V
V
OH
min = 1.35V
V
IL
min = -0.3V
V
IL
max = 0.6V
V
IH
min = 1.2V
V
IH
max = 2.0V
1.8V power domain.
In master mode, it’s
an output signal. In
slave mode, it is an
input signal.
