47
©2006 Sunrise Medical
QUICKIE ELECTRONICS SECTION
Power On / Off Options
This button turns the wheelchair control on and off. You can see if the wheelchair control is on by looking at the
lights just under the on/off button. If any of the lights are visible, the control is on.
Keyless Lock Feature
This is a programmable feature that can be Enabled or Disabled – Default Disabled. The lock is engaged by de-
pressing and holding the On/Off switch for a period of greater than 10 seconds and then simultaneously pushing the
joystick forwards.
The lock is disengaged by depressing and holding the On/Off switch for a period of greater than 5 seconds and
then simultaneously pulling the joystick backwards.
Audio acknowledgment of the lock engaged operation is by sounding the horn for 50ms. Audio acknowledgment of
the lock disengaged operation is by sounding the horn for 50ms 3 times, with 50ms “spacing” between the tones.
Battery Diagnostic Threshold
Battery under-voltage Error Threshold (Range – 13-23 volts - normally set to 16 volts) This is the voltage at •
which the control will monitor for a specifi ed period of time and will execute an error of 1 bar fl ash.
Battery Voltage Error Period (Range setting of 0 – 100 seconds - normally set to 30 seconds) This is the •
period of time in which the control will look at a lower voltage parameter and count a time out – prior to
execution of error
Battery Voltage Low Warning Threshold (Range setting of 13 – 23 volts - normally set to 18 volts) This is •
the voltage at which the control will give a Low Voltage warning normally set prior to the Under-voltage Error
Threshold.
