Quickie Rhythm - Adjustments Overview

74©2006 Sunrise Medical
SEATING SECTION
Refer to the following tables for the range of
adjustments for the Perfect Fit Seating System.
Narrow Center
Pan
Medium Center
Pan
Wide Center
Pan
12” – 17” 15” – 20” 19” – 24”
Front of Chair
Seat Pan Width
Seat Pan Width Table
Seat Frame Depth Table
Pan Wing Range
12-14 Deep 12” 12” - 16”
12-14 Deep 13” 13”- 16”
12-14 Deep 14” 14” - 17”
15-17 Deep 15” 15” - 19”
15-17 Deep 16” 16” - 19”
15-17 Deep 17” 17” - 20”
18-20 Deep 18” 18” - 22”
18-20 Deep 19” 19” - 22”
18-20 Deep 20” 20” - 23”
21-22 Deep 21” 21” - 25”
21-22 Deep 22” 22” - 25”
Depth Range
Front of
Chair
Seat Pan
Seat Back
Narrow Wing Wide Wing
Narrow Center Pan
12” - 13” 14” - 19”
Wide Center Pan
N/A 17” - 24”
Seat Back Width Table
Seat Back Width
Seat Pan
Adjustments
Fig 3.12
Fig 3.13
Fig 3.14
