SEATING SECTION
The Posterior Lateral Positioning Back contains:
Deeply curved lateral wings to provide a lateral •
hug
Headrest adjustment points•
Up to 7” width adjustment •
Up to 3” height adjustment•
Posterior lateral support (135 mm)•
The curved General Purpose Back contains:
Slight curvature•
Multiple T-nut mounting positions•
Multiple hardware mounting positions in the •
back
No size adjustment•
Up to 3” height adjustment•
Recline Options
Recline options include Manual Recline and Power
Recline with Shear Reduction using dual actuators and
keipers.
The Manual Recline Back Rest provides:
Maximum posterior back angle 40° from vertical, •
limited by Gear Reduction Mechanism (GRS).
Minimum anterior back angle 10 degrees.•
The backrest can be folded all the way down if •
the armrests are up and the back plates are an
inch off the seat.
Fig 3.4
Fig 3.5
Fig 3.6
