Operation
Load and Operate the Lamination Module
1. Load the printed roll against the disk. Tighten the core holder.
2. Load the lamination roll, move it along the supply shaft, and make it match with the web.
Tighten the core holder.
Important: The lamination roll always needs to be narrower than the web width.
