Mechanical condensate drain
A float opens or closes the outlet dependant on the level of the condensate in the bowl.
Drain connections
Condensate drain connections
Reference Designation
Da Automatic drain connection
Dm Manual drain valve
Da1 Automatic drain connection of the dryer (only on units with integrated dryer)
Dm1 Manual drain valve of the dryer (only on units with integrated dryer)
Instruction book
