Icon Description
Compressor element (LP, HP, ...)
Dryer
Fan
Frequency converter
Drain
Filter
Motor
Failure expansion module
Network problem
General alarm
Menu icons
Icon Description
Inputs
Outputs
Protections (Warnings, shutdowns)
Counters
Test
Regulation (Settings)
Instruction book
2920 7190 02 31
