<DEMOD>
<LHCP>
<PLsync val="LK"/>
<EsNo val="12.4dB"/>
<AGC val="2.45V"/>
<Mode val="8PSK"/>
<Spectrum val="NOR"/>
<PLFPS val="360"/>
<BCHUC val="0"/>
</LHCP>
<RHCP>
<PLsync val="LK"/>
<EsNo val="12.4dB"/>
<AGC val="2.52V"/>
<Mode val="8PSK"/>
<Spectrum val="NOR"/>
<PLFPS val="360"/>
<BCHUC val="0"/>
</RHCP>
</DEMOD>
This section reports the status of the PLsync (DVB-S2 physical layer baseband
packets being received), the signal quality (ES/No), the AGC voltage, the
demodulator mode (8PSK), the spectrum inversion (NORMAL), the number of
physical layer frames being received per second (PLFPS) and the number of
BCH uncorrectable frames in the last second (BCHUC) for both the LHCP and
RHCP demodulators.
