RadioLink RC4GS V2 User Manual

RadioLink Electronic Ltd
www.radiolink.com
21
example.
1. Throttle Reverse：NOR-REV
Hold RC6GS V2 V2 as the below pic. Normally, pull the throttle, the right track should be moving forward while
push the throttle and the right track should be backward.
If pulling the throttle and the left track moves backward; Or pushing the throttle and the left track moves
forward, meaning the initial throttle is reversed and needs to be set. Please refer to the “button operation”and
get into below interface to complete the setup.
* If the throttle reverse is correct, skip this throttle reverse setup.
2. Steering Reverse：NOR/REV
Hold RC6GS V2 V2 as the below pic. Normally, if turn the wheel right/clockwise, the left track should be
moving forward while turn the wheel left/anticlockwise and the left track should be backward.
Pull the throttle，right track moves forward，left track remains still
Enter
Exit
Dec(-)
Inc(+)
[REVERSE]
ST : REV CH4 :NOR
TH : REV CH5 :NOR
CH3: NOR CH6: NOR
6 - Channel
Radio Control System
9. ACCEL
10. IDLUP
11. SUB-TRIM
12. REVERSE
Enter
Exit
Dec(-)
Inc(+)
6 - Channel
Radio Control System
CH2（Throttle- Control motor forward/backward）
CH1 (Wheel-Control steering left/right)
RADIOLINK
receiver
R7FG

RadioLink RC4GS V2 Specifications

General

Channels	4
Frequency	2.4GHz
Model Memory	10 models
Failsafe	Yes
Gyro Sensitivity Adjustment	Yes
Channel Bandwidth	500KHz
Screen	LCD
Simulator	Yes
Model Type	Car, Boat
Display	LCD
Telemetry	Yes
Range	400m (open area)
Battery	4x AA (not included)
Spread Spectrum	FHSS
Operating Voltage	4.8V to 6.0V
Control Distance	400m
Weight	320g
Receiver	R6FG
Voltage Range	4.8V to 6.0V
Compatible Receivers	R6FG, R6F
Range (open area)	400m
Transmitter Power	Less than 20dBm
