RadioLink RC4GS User Manual

5
Size: 213 *117 * 115.5mm
Frequency: 2.4Ghz ISM Band（2400MHZ-2483.5MHz）
Channel: 4CH
Channel resolution: 4096, the regular jitter is 0.5us
Model: Cars/Boats
Modulation Mode: GFSK
Spread Spectrum: FHSS, 67 Channels Pseudo Random Frequency Sequence
Hopping 10 Modes Memory Storage
Antenna Length: 106mm
Control Distance: More than 400 meters ground
LCD Screen: 128*64 resolution, LCD back light
Transmitter Operating Voltage: 4.8-15.0V DC
Transmitter Battery: 4*AA or 2-4S lithium battery
Transmitter operating current: 80-120mA
RF power: <20dbm
Low Voltage alert: Yes (lower than 4.6V) , can be set when using 2-4S LiPo battery
Receiver: R6FG, R6F, R8EF, R8FM
3.2 Receiver
RC4GS comes with R6FG, 2.4GHz 6 channels receiver, gyro integrated and HV servo
supported.
Simulator Port
USB Upgrade Port
Power Switch
Throttle Trigger

RadioLink RC4GS Specifications

General

Channels	4
Frequency	2.4GHz
Model Memory	10 models
Modulation Mode	FHSS
Screen	LCD
Low Voltage Alert	Yes
Weight	320g
Modulation	FHSS
Power Supply	6V DC (4 AA batteries)
Frequency Band	2.4GHz
Receiver	R4FGM
Simulator	Yes
Model Type	Car/Boat
Battery	4 AA batteries
Operating Voltage	4.8~8.4V
