Radiolink Electronic Ltd
www.radiolink.com
There are 4 more parameters displaying next to SYSTEM : Model data selected/T8FB voltage(TX)/RSSI/
Model voltage(EXT, works only with RadioLink receivers of telemetry function R7FG or R8F).
Parameters Setting Steps and Multiple Model Data Storage
When parameters need to be modified, click READ first to input the original data from T8FB into the APP,
then modify as wish and click WRITE to output the modified data to T8FB.
Click LOAD and a pop out of ‘Model Select’ will display, click NEW to create a new file
/model/Model-New.txt. Click it to select and tab the file name next to the SYSTEM to rename. Setup all the
data then click STORE to save under the personalized name.
When parameters STORE as TXT file need to be input, click LOAD first to select from the saved data files
into the APP then click WRITE to copy them to T8FB.
Note If the new file created is forgotten to rename but STORE as Model-New, the data in this file will be
cleaned automatically when trying to create another new file sharing the same file name.
There are 7 parameter setup menus:
The above menus are all available on Android APP V7.1 and above. Menu No 1. to 4 are available on Apple
APP. The latest APP will be frequently updated on RadioLink official website www.radiolink.com .
3.3.1 SERVO Menu
The 8 rectangles show the CH1-CH8 servos range (4 basic
channels and 4 auxiliary channels) from left to right. CH1--Aileron,
CH2 - Elevator, CH3 - Throttle,CH4--Rudder, CH5 to CH8--Auxiliary
channels
3.3.2 BASIC Menu
There are 6 parameters to setup including” REV” “SUB” “EPA-L” “EPA-R” “F/S” “DELAY”
