RadiSys PL35Q - Page 14

2
Product Specification
14
PL35Q motherboard power consumption
These tests were run on a revision 1.01 PL35Q motherboard.
Table 2. PL35Q power consumption — DOS (stable)
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
46
Voltage (V) 118.90 12.22 12.22 11.93 5.12 3.36 5.08 5.12 12.22
Current (A) 0.62 2.01 0.25 0.02 0.98 2.04 0.02 0.41 0.31 Efficiency (%)
Power (W) 73.72 24.56 0.00 3.06 0.24 5.02 6.85 0.10 2.10 3.79
62
Vdrop Result — PASS PASS PASS PASS PASS PASS PASS PASS
Table 3. PL35Q power consumption — BIOS (stable)
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
46
Voltage (V) 118.90 12.22 12.22 11.93 5.12 3.35 5.08 5.12 12.22
Current (A) 0.64 1.96 0.31 0.01 0.96 2.02 0.02 0.43 0.33 Efficiency (%)
Power (W) 76.10 23.95 0.00 3.79 0.12 4.92 6.77 0.10 2.20 4.03
60
Vdrop Result — PASS PASS PASS PASS PASS PASS PASS PASS
Table 4. PL35Q power consumption — Windows desktop idle (stable)
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
44
Voltage (V) 119.70 12.22 12.22 11.94 5.12 3.36 5.08 5.12 12.22
Current (A) 0.62 1.85 0.29 0.03 1.03 2.09 0.02 0.43 0.25 Efficiency (%)
Power (W) 74.21 22.61 0.00 3.54 0.36 5.27 7.02 0.10 2.20 3.06
60
Vdrop Result — PASS PASS PASS PASS PASS PASS PASS PASS
Table 5. PL35Q power consumption — CPU stress (max)
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
66
Voltage (V) 119.40 12.20 12.20 11.93 5.12 3.35 5.08 5.12 12.20
Current (A) 0.82 3.63 0.27 0.01 1.01 2.08 0.01 0.43 0.34 Efficiency (%)
Power (W) 97.91 44.29 0.00 3.29 0.12 5.17 6.97 0.05 2.20 4.15
68
Vdrop Result — PASS PASS PASS PASS PASS PASS PASS PASS
Table 6. PL35Q power consumption — Windows stress (max)
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
49
Voltage (V) 119.20 12.21 12.22 11.93 5.12 3.36 5.08 5.12 12.22
Current (A) 0.67 2.04 0.28 0.05 1.15 2.27 0.01 0.47 0.33 Efficiency (%)
Power (W) 79.86 24.91 0.00 3.42 0.60 5.89 7.63 0.05 2.41 4.03
61
Vdrop Result — PASS PASS PASS PASS PASS PASS PASS PASS
