Electrical specifications
15
PL35Q motherboard power leakage
These tests were run on a revision 1.01 PL35Q motherboard.
Table 7. PL35Q power leakage — Suspend (S3) with LAN connected
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
2
Voltage (V) 119.70 0.00 0.00 0.00 0.10 0.01 5.08 0.10 0.00
Current (A) 0.07 0.01 0.02 0.02 0.01 0.00 0.36 0.04 0.02 Efficiency (%)
Power (W) 8.38 0.00 0.00 0.00 0.00 0.00 0.00 1.83 0.00 0.00
—
Vdrop Result — PASS PASS PASS PASS PASS — PASS PASS
Table 8. PL35Q power leakage — Suspend (S3) without LAN connected
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
2
Voltage (V) 119.60 0.06 0.00 0.00 0.10 0.01 5.07 0.10 0.00
Current (A) 0.06 0.01 0.00 0.03 0.00 0.03 0.43 0.01 0.02 Efficiency (%)
Power (W) 7.18 0.00 0.00 0.00 0.00 0.00 0.00 2.18 0.00 0.00
—
Vdrop Result — PASS PASS PASS PASS PASS — PASS PASS
Table 9. PL35Q power leakage — Hibernate (S4) with LAN connected
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
1
Voltage (V) 119.40 0.00 0.00 0.00 0.00 0.00 5.08 0.00 0.00
Current (A) 0.05 0.00 0.02 0.00 0.01 0.00 0.14 0.01 0.01 Efficiency (%)
Power (W) 5.97 0.00 0.00 0.00 0.00 0.00 0.00 0.71 0.00 0.00
—
Vdrop Result — PASS PASS PASS PASS PASS — PASS PASS
Table 10. PL35Q power leakage — Hibernate (S4) without LAN connected
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
1
Voltage (V) 119.30 0.00 0.00 0.00 0.00 0.00 5.08 0.00 0.00
Current (A) 0.06 0.01 0.00 0.00 0.01 0.00 0.24 0.02 0.00 Efficiency (%)
Power (W) 7.16 0.00 0.00 0.00 0.00 0.00 0.00 1.22 0.00 0.00
—
Vdrop Result — PASS PASS PASS PASS PASS — PASS PASS
Table 11. PL35Q power leakage — Soft Off (S5) with LAN connected
AC
Input
4-pin 8-pin 20/24-pin main power connector Peripheral (HDD) Consumption (W)
+12V +12V +12V -12V +5V +3.3V +5V
STBY
+5V +12V
1
Voltage (V) 119.30 0.00 0.00 0.00 0.00 0.00 5.08 0.00 0.00
Current (A) 0.05 0.00 0.01 0.01 0.00 0.02 0.14 0.01 0.00 Efficiency (%)
Power (W) 5.97 0.00 0.00 0.00 0.00 0.00 0.00 0.71 0.00 0.00
—
Vdrop Result — PASS PASS PASS PASS PASS — PASS PASS
