- 70 -
Procedure for activation of dosing mode
Select <
Dosing> mode, home screen featuring dosing pictogram in a top bar is
automatically displayed.
Info field provides the following information:
• Bar graph with target value
• Net weight,
• Tare weight,
• User,
• Keys: parameters, adjustment, print header, print footer, specify target value, product, user,
databases.
15.1. SUPPLEMENTARY SETTINGS FOR DOSING MODE
The supplementary settings enable adjusting the working mode to your needs and requirements.
For means of operation of these functions read point 8.10 „WEIGHING mode settings”.
You can place the bar graph within information field area. Below the bar graph, Min and Max
threshold values are displayed.
15.2. DOSING – QUICK ACCESS KEYS
Each working mode features automatically displayed set of default keys. The set can be modified by
assigning out-of-list quick access keys to on-screen keys. Such operation requires particular
permissions level.
Read section 7.6.1 for list of quick access keys.
15.3. MAKING USE OF PRODUCTS DATABASE FOR DOSING OPERATION
The operator can use target value assigned to a product or values recorded in Product Database.
Additionally, option of user-defined temporary target values is at user disposal. Mass field is the
target value for Product Database.
PROCEDURE 1 – selecting product from Products Database
• Press < Products Database> button.
• Using product list, select the product that is to be weighed.
• Target and tolerance values are displayed automatically within bar graph area.
• Target value with minus sign is displayed
• The balance displays threshold values under the bar graph within INFO area.
