RADWAG WLC/A2 User Manual

10
3. Remove the hole plug.
4. Mount the hook and put the
scale bottom side down.
6. START-UP AND OPERATION
6.1. Levelling
To level the weighing instrument turn its feet. Keep turning the feet until the air
bubble takes central position:
6.2. Connecting the Scale to the Mains
The weighing device can be connected to the mains only with a power supply
that comes standard with the particular model.

RADWAG WLC/A2 Specifications

General

Readability	0.01 g
Pan Size	195 x 195 mm
Calibration	External
Display	LCD (backlit)
Communication	RS 232
Power Supply	100 - 240 V AC 50 / 60 Hz
Repeatability	0.01 g
Stabilization Time	3 s
Operating Temperature	+15°C - +30°C
