Radwin RW-5200-0250 User Manual

ODU - HBS and HSU
Appendix A
Band
Occupied
Frequency range
[GHz]
Compliance
Channel Bandwidth
5 MHz
10 MHz
20 MHz
40 MHz
IC 5.4
5.480 – 5.590
5.660 – 5.715
IC RSS-210
Yes
FCC/IC 5.3
5.260 - 5.340
FCC 47CFR, Part 15, Subpart E and IC RSS-210
Yes
FCC/IC 4.9
4.940 - 4.990
FCC 47CFR, Part 90, Subpart Y and IC RSS-111
Yes
WPC India 5.8
5.825 – 5.875
GSR-38
Yes
MII China 5.8
5.730 – 5.845
MII China
Yes
ETSI 5.8
5.735 – 5.865
ETSI EN 302 502
Yes
ETSI 5.4
5.480 – 5.715
ETSI EN 301 893
Yes
ETSI 5.3
5.160 – 5.340
ETSI EN 301 893
Yes
Universal 6.0
5.690– 6.060
N/A
Yes
Universal 5.9
5.730 – 5.960
Yes
Universal 5.4
5.490 – 5.710
Yes
Universal 5.3
5.140 – 5.345
Yes
Universal 4.9
4.890 - 5.010
Yes
ODU with Integrated Antenna
37.1/14.84(W) x 37.1/14.84(H) x 9.00/3.6(D) cm/in; 3.5 kg / 7 lbs
ODU Connectorized
19.5/7.7(W) x 27.0/10.8(H) x 5.5/2.2(D) cm/in; 1.8 kg / 3.6 lbs
ODU HSU SFF (Embedded antenna)
19.5/7.7(W) x 27.0/10.8(H) x 7/2.8(D) cm/in; 1.8 kg / 3.6 lbs
Power Feeding
Dual feeding, -20 to -60 VDC (AC/DC converter is available)
Power Consumption - alone
HBS: <2W, HSU: <20W
Architecture
ODU: Outdoor Unit with Integrated Antenna, Connectorized for External
Antenna or Embedded
PoE device for Ethernet only
ODU to PoE Interface
HBS:
• Outdoor RADWIN CAT-5e cable. maximum cable length: 100m for 10/
100BaseT.
• Outdoor RADWIN CAT-5e cable. maximum cable length: 75m for
1000BaseT.
HSU:
Outdoor CAT-5e cable; maximum cable length: 100 m (10/100BaseT)
Management Application (per link)
RADWIN Manager
Protocol
SNMP and Telnet
NMS
RADWIN NMS
Operating Temperatures
HBS/HSU: -35°C to +60°C / -31°F to +140°F
Humidity
HBS/HSU: Up to 100% non-condensing, IP67
FCC/IC (cTUVus)
UL 60950-1, UL 60950-22, CAN/CSA C22.2 60950-1, CAN/CSA C22.2 60950-22
ETSI/IEC
EN/IEC 60950-1, EN/IEC 60950-22
