RFP and HSS
When HSS is used, the RFP for the collocated radios must be selected manually.
RADWIN 5000 HPMP radios use the Time Division Duplex (TDD) mechanism.
Under HSS, TDD enables synchronization of transmission for the collocated units as shown in
Figure 7-9:
Figure 7-9: Radio Frame Pattern
Five RFP types (A to E) are available. Under HSS the RFP must be configured by the user
depending on the type of the radio products, services and channel bandwidth in accordance
with the Table 7-3 and Table 7-4.
The tables describe the efficiency of the air interface according to the RFP type, radio prod-
ucts mix, services and channel bandwidth. The tables may also be viewed in the RADWIN
Manager and in the Link Budget Calculator. The efficiency of the air interface will vary accord-
ing to the product used.
Table 7-2: Radio Frame Pattern Table - RADWIN 5000 HBS
Legend:
Best fit - optimal RFP choice for TDM and Ethernet services.
Available - available RFP for TDM and Ethernet services, but not optimal.
N/A - service unavailable
