RADWIN 5000 HPMP User Manual
Release 3.1.00
B-2
User Port Connectors Appendix B
Table B-2: ODU/HSS Unit Connection Pinout (Continued)
Color
ODU
RJ-45
HSS UNIT
RJ-45
White/Brown
7
7
Brown
8
8
User Port Connectors
LAN Port
The LAN 10/100BaseT interface terminates in an 8-pin RJ-45 connector, wired in accordance
to Table B-3.
Example for connecting the alarm connector
Table B-3: Fast Ethernet Connector Pinout
Function
Signal
Pin
Transmit Data (positive)
TD (+)
1
Transmit Data (negative)
TD (–)
2
Receive Data (positive)
RD (+)
3
Receive Data (negative)
RD (–)
6
DC Power Terminals
DC PoE
Table B-4: Terminal Block 2-pin -48VDC
Function
Pin
+
Right
–
Left
