Chapter 8
Pole and Wall Installation
ODU Mounting Kit Contents
Table 8-1: Bill of Materials: ODU mounting kit
Item
Qty
Large Clamp (see Figure 8-1)
1
Small Clamp (see Figure 8-2)
1
Arm (see Figure 8-3)
1
Screw hex head M8x40
4
Screw hex head M8x70
2
Washer flat M8
4
Washer spring M8
3
M8 Nuts
2
Figure 8-1: Large ClampFigure 8-2: Small Clamp Figure 8-3: Arm
