RADWIN 5000 HPMP User Manual
Release 3.1.00
3-7
Additional Tools and Materials Required
Chapter 3
Additional Tools and Materials Required
The following is a list of the equipment and materials required to install RADWIN 5000 HPMP
hardware.
Tools and Materials
• Crimping tool for RJ-45 (if the ODU-PoE cable is without connectors)
• Spanner/wrench 13 mm (½”)
• Drill (for wall mounting only)
• Cable ties
• Sealing material
Cables and connectors
• ODU grounding cable 12AWG
• ODU-PoE cable (outdoor class, CAT-5e, 4 twisted pairs, 24AWG), up to 100 m. for
100BaseT connection. For a 1000BaseT connection (HBS only) use an ODU-PoE cable
no longer than 75m.
Note
For 1000BaseT, you should use RADWIN supplied ODU-PoE cables, which
guarantee 1Gb performance. RADWIN cannot guarantee 1Gb performance
if you use third party cables.
• A crossed Ethernet LAN cable is required if you set up ODUs using the “Local Connec-
tion” method.
Hardware Installation Sequence
The following steps are required to install a RADWIN 5000 HPMP system:
1. Mounting the ODUs, page page 3-8.
2. Mounting the external antennas (if used), page page 3-9.
3. Mounting the Lightning Protection devices (if used), page page 3-9.
4. Outdoor connections, page page 3-9.
5. Connecting the PoEs, page page 3-10.
6. Other Indoor connections, page page 3-10.
7. Aligning the HSUs to the HBS, page page 3-10.
See Figure 3-8 below, which illustrates a typical installation of a RADWIN 55xx HSU with an
external antenna.
