HBS and HSU ODU Package Contents
Chapter 3
• Link Budget Calculator
• Label showing the MAC address and the alternative Community string. The label is
self-adhesive. You should keep this label safe
• Cable glands (to be used with the ODU-PoE cable)
Figure 3-1: ODU Mounting kit
The ODU comes in two basic form factors as shown in Figure 3-2 below:
Front
Rear
Connectorized
Integrated Antenna
Figure 3-2: ODU Form Factors
• Integrated Antenna ODU
This ODU has an integrated 370mm (1.2ft) flat panel antenna. The ODU contains both
the radio and the antenna as a single unit housed in a weatherproof case.
