RC3000E (P100R001) Product Description
3 Technical specifications
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
9
3.1.3 Overall parameters
Table 3-3 lists overall parameters of the RC3000E.
Table 3-3 Overall parameters
Parameter
Description
Physical structure
1U device
Dimensions (mm)
440 mm (width) × 360 mm (depth) × 44.5 mm (height)
Net weight (kg)
4 kg
3.2 Interface specifications
3.2.1 Interface specifications of uplink interface card
E1 interface
Table 3-4 lists specifications of the E1 interface.
Table 3-4 Specifications of the E1 interface
Parameter
Description
Nominal bitrate
2048 kbit/s ± 50 ppm
Coding type
HDB3
Interface impedance

75 Ω (unbalanced interface)

120 Ω (balanced interface)
Electrical feature
Comply with the ITU-T G.703 standard.
Frame structure
Comply with the ITU-T G.704 standard.
Jitter
Comply with the ITU-T G.823 standard.
E1 connector type

Balanced: RJ45 connector

Unbalanced: CC3 female connector
E1 cable type

For unbalanced signals, we recommend you to use the SYV
75-2-2 coaxial cable with the maximum transmission length
of 200 m.

For balanced signals, we recommend using the 0.6 mm (22
AWG) twisted-pair cable.
Optical interface
Table 3-5 lists specifications of the optical interface.
