RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
18
–
1: No.1 way E1
2: No.2 way E1
3: No.3 way E1
4: No.4 way E1
ON
Unbalanced (75 Ω)
Unbalanced (75 Ω)
Unbalanced(75 Ω)
Unbalanced (75 Ω)
OFF
Balanced (120 Ω)
Balanced (120 Ω)
Balanced (120 Ω)
Balanced (120 Ω)
SW3: choose the matched impedance when No. 1–4 ways of E1 work in balanced or
unbalanced mode.
–
1: No.1 way E1
2: No.2 way E1
3: No.3 way E1
4: No.4 way E1
ON
75 Ω (unbalanced)
75 Ω (unbalanced)
75 Ω (unbalanced)
75 Ω (unbalanced)
OFF
120 Ω (balanced)
120 Ω (balanced)
120 Ω (balanced)
120 Ω (balanced)
SW2: choose No. 5–8 ways of E1 to work in balanced or unbalanced mode.
–
1: No.5 way E1
2: No.6 way E1
3: No.7 way E1
4: No.8 way E1
ON
Unbalanced (75 Ω)
Unbalanced (75 Ω)
Unbalanced (75 Ω)
Unbalanced (75 Ω)
OFF
Balanced (120 Ω)
Balanced (120 Ω)
Balanced (120 Ω)
Balanced (120 Ω)
SW4: choose the matched impedance when No. 5–8 ways of E1 work in balanced or
unbalanced mode.
–
1: No.5 way E1
2: No.6 way E1
3: No.7 way E1
4: No.8 way E1
ON
75 Ω (unbalanced)
75 Ω (unbalanced)
75 Ω (unbalanced)
75 Ω (unbalanced)
OFF
120 Ω (balanced)
120 Ω (balanced)
120 Ω (balanced)
120 Ω (balanced)
SW5: choose the type of the subcard
–
1: Reserved
2: Type [2]
3: Type [1]
4: Type [0]
ON
Reserved
0
0
0
OFF
Reserved
1
1
1

Type [2: 4] = 100: the RC3000E-UP-8E1-BL

Type [2: 4] = 011: the RC3000E-UP-8E1
4.1.4 Technical specifications
Dimensions: 155 mm (Width) × 100.5 mm (Depth) × 25 mm (Height)
