RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
23
No.
Description
Status
Description
5
L LOS1
Red
Local No.1 way E1 signal LOS alarm LED on the 2E1
interface

Red: some local No.1 way E1 signal lost.

Off: no local No.1 way E1 signal lost.
The LED is disabled in mode 3.
6
L LOS2
Red
Local No.2 way E1 signal LOS alarm LED on the 2E1
interface

Red: some local No.2 way E1 signal lost.

Off: no local No.2 way E1 signal lost.
The LED is disabled in mode 3.
7
R LOS1
Red
Remote No.1 way E1 signal LOS alarm LED on the
2E1 interface

Red: some remote No.1 way E1 signal lost.

Off: no remote No.1 way E1 signal lost.
The LED is disabled in mode 1 and mode 3.
8
R LOS2
Red
Remote No.2 way E1 signal LOS alarm LED on the
2E1 interface

Red: some remote No.2 way E1 signal lost.

Off: no remote No.2 way E1 signal lost.
The LED is disabled in mode 1 and mode 3.
9
LNK
ACT
Green
Link status LED

Green: the link connection is normal.

Blinking green: data is transmitting or receiving on
the interface.
10
100M
Green
Ethernet interface rate LED

Green: the interface rate is 100 Mbit/s.

Off: the interface rate is 10 Mbit/s.
