RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
31
SCIC PIN
E&M
channel
Description
Cable color
40
6

4-wire: receive audio A.

2-wire: idle
Yellow background with
blue loop
41

4-wire: receive audio B.

2-wire: idle
Blue background with
yellow loop
17

4-wire: send audio A.

2-wire: receive/send audio A.
Yellow background with
orange loop
18

4-wire: send audio B.

2-wire: receive/send audio B.
Orange background with
yellow loop
42
Signaling M wire
Yellow background with
green loop
43
Signaling E wire
Green background with
yellow loop
19
7

4-wire: receive audio

2-wire: idle
Yellow background with
brown loop
20

4-wire: receive audio B.

2-wire: idle
Brown background with
yellow loop
44

4-wire: send audio A.

2-wire: receive/send audio A.
Yellow background with
grey loop
45

4-wire: send audio B.

2-wire: receive/send audio B.
Grey background with
yellow loop
21
Signaling M wire
Purple background with
blue loop
22
Signaling E wire
Blue background with
purple loop
46
8

4-wire: receive audio A.

2-wire: idle
Purple background with
orange loop
47

4-wire: receive audio B.

2-wire: idle
Orange background with
purple loop
23

4-wire: send audio A.

2-wire: receive/send audio A.
Purple background with
green loop
24

4-wire: send audio B.

2-wire: receive/send audio B.
Green background with
purple loop
48
Signaling M wire
Purple background with
brown loop
49
Signaling E wire
Brown background with
purple loop
25
Idle
–
Purple background with
grey loop
