Product Description

R&S

RT-ZC31

17User Manual 1801.4949.02 ─ 01

1 = JAW UNLOCKED indicator

2 = Current direction indicator

3 = Opening lever

4 = Sensor aperture

5 = Jaws

6 = Sensor head

JAW UNLOCKED indication

If the sensor head is unlocked, you can see this indication on the probe.

Current direction indication

Clamp the device to the conductor so that the direction in which the current being

measured is flowing matches the arrow.

Opening lever

Operating lever for opening the sensor head. Always use this lever to open the

sensor head.

Sensor aperture

A conductor to be measured has to pass through this aperture.

Sensor head

The sensor head clamps on the conductor being measured, and carries out the

actual current measurement.

Description of the Probe
