8 Gas connection
Gas connection 61, 62, 11, 12
¾“ pipe
¾“
main gas line
shut off
LEFT SIDE VIEW
Quick connect gas line i. e.
Dormont 36“ ¾“
Gas connection 21, 22
¾“ pipe for 201
1“ pipe for 202
¾“ for 201
1“ for 202
main gas line
shut off
LEFT SIDE VIEW
Quick connect gas line i. e.
Dormont 36“ ¾“ for 201
1“ for 202
