Technical data 4
26
4.3.2 Technical data of basic equipment
Dimensions:
Data AXIS 30.2
AXIS 40.2
AXIS 30.2 EMC
AXIS 40.2 EMC
Overall width 240 cm
Overall length 141.5 cm
Filling level
(basic machine)
107 cm
Distance between centre of gravity and lower link point 65.5 cm
Filling width 230 cm
Working width
1
1. Working width depending on fertiliser and disc type
12 - 42 m
PTO speed min. 450 rpm
max. 650 rpm
Capacity 1,400 l
Mass flow
2
2. Max. mass flow depending on fertiliser type
max. 500 kg/min
Hydraulic pressure max. 200 bar
Sound pressure level
3
(measured in the closed driver’s
cab of the tractor)
3. Since the sound pressure level of the machine can only be determined when the tractor is run-
ning, the actual measured value is greatly dependent on the tractor type being used.
75dB(A)
