Commissioning 7
68
4. Loosen the adjustment nut [2] for the numeric scale using the adjustment le-
ver of the machine.
Correcting the spreading distance
The specifications in the provided assembly manual are standard values. If there
are deviations in the fertiliser quality, it may be necessary to correct the setting.
For reducing the spreading distance, move towards the spreading disc
(smaller numbers).
For increasing the spreading distance, move away from the spreading disc.
(greater numbers).
7.10 Setting the TELIMAT special equipment
The TELIMAT is a remote-controlled full and limited border spreading unit for
working widths of 12 - 42 m (or boundary spreading only, depending on the fer-
tiliser type).
The TELIMAT T is mounted on the right side of the machine in the direction of
travel. You can control the TELIMAT set-up from the tractor via a single-acting
control valve.
7.10.1 Setting the TELIMAT
You prepare the TELIMAT for spreading in accordance with the fertiliser type,
the working width and the desired type of boundary spreading (boundary or
full border spreading).
NOTICE
The attachment of the TELIMAT T25 to the machine is described in detail in a
separate assembly instruction manual. An assembly manual is included in the
scope of delivery of the TELIMAT unit.
NOTICE
The setting values for TELIMAT can be obtained from the fertiliser chart.
