Raven RS1 - Route the RS1 Cabling to Direcsteer

Chapter5
l
Tie down the harnesses so they are free from vibration and friction.
Route the RS1™ Cabling to DirecSteer
1. Locate the battery of the tractor, normally located on the right side of the tractor,
below the door/window.
2. Leave the black and red wires of the DirecSteer power cable (P/N 115-8000-473) near
the battery to ensure the system can connect to power later.
CAUTION
Do not connect the system power cable to the vehicle igni-
tion or battery until all system components are mounted
and all electrical connections are completed.
