Raven SCS 4600 Operator's Manual

CALIBRATION REFERENCE SHEET
(Record Cal Values for future reference or contacting service technician)
Circle Settings Selected
UNITS US SI TURF
(ACRES) (HECTARES) (1000 SQUARE FEET)
SPEED SP1 SP2
SENSOR (WHEEL (RADAR)
SPEED)
CONTROL LIQUID GRAN 1 GRAN 2 GRAN 3
(SINGLE BED) (SPLIT BED) (DUAL FLOW)
VALVE STANDARD FAST FAST CLOSE PWM PWM
VALVE VALVE VALVE VALVE CLOSE
VALVE
BOOM METER RATE
WIDTHS CAL CAL
1__________ 1__________ 1__________
2__________ 2__________ 2__________
3__________ 3__________ 3__________
4__________
5__________ VALVE VOLUME IN SPEED CAL
6__________ CAL TANK __________
7__________
8__________ 1__________ 1__________
9__________ 2__________ 2__________
10_________ 3__________ 3__________
DATA ENTRY EXAMPLE: TO ENTER VALVE CAL
1. PRESS VALVE CAL KEY.
2. PRESS ENTER KEY.
3. PRESS KEYS REQUIRED, TO ENTER PROPER NUMBER.
(EXAMPLE: KEYS FOR 2123)
4. PRESS ENTER KEY AGAIN.
