Raven SCS 4600 Operator's Manual

60
2) Optional 9 pin to 9 pin cable pinout (P/N 115-0171-395).
CTS 8 7
RTS 7 8
TXD 3 2
RXD 2 3
GND 5 5
APPENDIX 10
SERIAL INTERFACE
1) Changing RATE CAL by remote computer.
a) Configuration of RS-232C serial port:
9600 Baud Rate
NO Parity
8 Data Bits
2 Stop Bits
b) Setup Raven Console to pass data through comport. See DATALOG options
under DATA MENU section.
c) Data stream to Raven Console.
EXAMPLE: Change Product 1 rate to 130.0
Change Product 2 rate to 0.0
Change Product 3 rate to 102.7
$R,RC,1300,0,1027<CR><LF>
Decimal point is not sent from Remote Computer to Raven Console.
Start of
Communication
string
Rate Cal
Line Feed
Carriage Return
Rate 1
RAVEN
CONSOLE
9 PIN
COMPUTER/
GPS
9 Pin
Rate 2
Rate 3
