8 Unverferth NutriMax™ Applicator ISO Steerable Hitch Installation & Operation Manual
UNVERFERTH INSTALLATION KIT
TABLE 2. Unverferth Installation Kit (P/N 412003BFS)
Item Description Part Number Qty.
Bracket - Sensor Mounting 410905 1
Bracket - Steerable Hitch Valve Mounting 410916 1
Bracket - Proximity Switch Mounting 410920 1
Bracket - Node Mounting 410927 1
Bracket - Cylinder Lock 411149 2
Tie - Cable 9000107 10
Hydraulic Hose - 3/4” JIC (F) to 3/4” JIC (F) - 15” 9001228 1
Hydraulic Hose - 9/16” JIC (F) to 9/16” JIC (F) - 43-1/2” 90030611
Hydraulic Hose - 9/16” JIC (F) to 9/16” JIC (F) - 31” 9003113 1
Hydraulic Hose - 3/4” JIC (F) to 3/4” SAE O-Ring (M) - 186” 9007545 2
Clamp - Poly Double 9004367 3
U-Bolt 9004454 2
Filter - 120 Micron Hydraulic 9005403 1
Cylinder - 3-1/2” x 12 9005673 2
Marker - Hose 9005870 1
Marker - Hose 9005871 1
Screw - Flanged 9006040 2
Fitting - 9/16” JIC (M) to 9/16” SAE O-Ring 90° Elbow 9006171 2
Fitting - 9/16” JIC (M) to 3/4” SAE O-Ring 90° Elbow 9006173 2
