Raychem C910-485 - 4.2 Console Mode Menus: Alarm Output Normal State; 4.2 Console Mode Menus: Alarm Output State Keystrokes

nVent.com | 50
4.2.30 Alarm Output Normal State
Purpose
Configures both the alarm output relays (dry contact and AC alarm)
for normally open or normally closed operation. The normal condition
is assumed to be when the HTC is powered and no alarms exist.
Setting/Range
Normally Open (N.O.) or
Normally Closed (N.C.)
Factory Default
Normally closed
